Description:

The HP-40A is a two-post lift electro-hydraulic with lower bridge, designed for lifting vehicles up 4000 kg . It has a greater lifting capacity with lower power consumption, by optimizing the design. This lift has triple safety device: electrical, hydraulic and mechanical.

CharacteristicsData sheetPhoto GalleryAccessories
  • Anchors security features that protect the hydraulic system.
  • Hydraulics reliable, long lasting and almost maintenance-free.
  • Extendable loading arms with height adjustable supports and systems combination of rubber pads.
  • Robust sheet steel post of 5 mm.
  • Automatic Lock loading arms (unlocks in the lowest position).
  • Control synchronous undisturbed and secure, using steel cables 12 mm in diameter.
  • Lower protective plate for hydraulic hoses and steel cables.
  • Capacity: 4,000 kg
  • Maximum lift height: 1,900 mm
  • Distance between post: 2,815 mm
  • Overall width: 3,425 mm
  • Power supply: 220 V single-phase and three-phase 380
  • Weight: 670 kg
